| Brand Name: | N/A |
| Model Number: | DHM1666 |
| MOQ: | 500MTS |
| Payment Terms: | T/T |
88/12 Polyester Elastane Gingham Plaid 120GSM For Sportswear
This 120GSM gingham plaid fabric combines 88% polyester with 12% spandex to deliver a classic checkerboard aesthetic with lightweight stretch, engineered specifically for sportswear that needs breathability, flexibility, and casual style. The gingham pattern – evenly spaced contrasting squares – provides a clean, preppy look that stands out from solid activewear, while the 12% spandex content offers 4‑way stretch (over 150% elongation) with reliable recovery, allowing the fabric to move freely during yoga, training, or dance. At 120 grams per square meter, the fabric is ultra‑lightweight and breathable, making it ideal for summer sportswear, swimwear cover‑ups, and casual tops. The polyester base ensures rapid moisture wicking (sweat dries in about 18 minutes), colorfastness, and easy care. For gingham sports bras, dance leotards, festival tops, and lightweight lining applications, this stretch plaid delivers the perfect balance of pattern, performance, and comfort.
| Parameter | Value / Range |
|---|---|
| Model Code | DHM1666 |
| Composition | 88% Polyester / 12% Spandex |
| Pattern | Gingham plaid (even checkerboard) |
| Weight | 120 GSM ±5% |
| Finished Width | 150 cm (59 inches) |
| Stretch Type | 4‑way |
| Stretch Factor (Warp / Weft) | > 150% / > 170% (ASTM D2594) |
| Recovery (after 150% stretch) | > 86% |
| Air Permeability | 200 – 260 CFM (ASTM D737) |
| Water Absorption | < 0.2% of fabric weight |
| Drying Rate (from soaked) | 18 minutes at 23°C, 50% RH |
| Moisture Wicking (Capillary Rise) | > 7 cm in 10 minutes |
| Tensile Strength (Warp) | > 130 N / 5 cm (ASTM D5034) |
| Tear Strength (Weft) | > 14 N (ASTM D2261) |
| Pilling Resistance | Grade 4 (ISO 12945‑2) |
| Color Fastness to Light | Grade 4 (AATCC 16, 40 hours) |
| Color Fastness to Perspiration | Grade 4‑5 (AATCC 15) |
| Shrinkage (after 5 washes, 40°C) | < 2% |
| Opacity | Semi‑opaque – dark prints fully opaque; light prints slightly sheer |
| Standard Gingham Colors | Black/white, navy/white, red/white, pink/white, etc. |
| Custom Check Colors | Yes (any two‑color combination, MOQ 500 m) |
| Lead Time (stock colors) | 25‑30 days |
| Lead Time (custom colors) | 25‑30 days + 10‑12 days lab dip |
Why this stretch gingham plaid is perfect for lightweight sportswear:
Classic gingham aesthetic – Timeless checkerboard pattern adds a fresh, playful look to activewear, dancewear, and festival tops.
4‑way stretch (over 150% elongation) – Moves freely with every pose, jump, or stretch. No restriction, no binding.
120GSM ultra‑lightweight – Almost weightless. Ideal for summer layering, swim cover‑ups, and breathable linings.
Breathable (200‑260 CFM) – Air flows freely, preventing overheating during high‑intensity activity.
Quick drying (18 minutes from soaked) – Sweat evaporates rapidly. Perfect for poolside wear and humid climates.
Soft hand and comfortable – Fine polyester/spandex yarns feel smooth against the skin, with no scratchiness.
Easy care – Machine wash cold, hang dry. Resists shrinking, fading, and pilling.
Primary sportswear applications for 120GSM stretch gingham plaid:
Gingham sports bras and bralettes
Dance leotards and bodysuits
Festival and rave tops (sheer overlay or standalone)
Swimwear cover‑ups (quick dry, stylish)
Yoga tops and shorts (casual gingham style)
Lightweight jacket and bag linings
Casual summer t‑shirts and tank tops
Q1: Is the gingham pattern printed or woven?
The gingham pattern is created using contrasting yarns during knitting – it is not printed. This means the pattern will never crack, peel, or fade. The check is permanent and remains sharp wash after wash.
Q2: Is 120GSM see‑through?
Dark gingham combinations (black/white, navy/white) are semi‑opaque – they may be slightly sheer under bright light but are generally fine for tops and cover‑ups. Light color combinations (white/pink, white/red) are sheer by design. For opaque use, we recommend layering over a solid base or choosing a darker base color.
Q3: Can this fabric be used for swimwear?
Yes, for recreational swimwear and cover‑ups. The polyester/spandex blend is chlorine‑resistant for moderate use. For frequent pool use, upgrade to a chlorine‑resistant finish (available on request, MOQ 1000m).
Q4: Is a recycled polyester version available for this gingham plaid?
Yes. We offer a GRS‑certified recycled polyester version of this exact 120GSM gingham fabric. The recycled yarn is sourced from post‑consumer PET bottles. The mechanical properties – tear strength (>14N), stretch (>150%), air permeability (200‑260 CFM) – are all within 5% of the virgin version. The gingham pattern, soft hand, and colorfastness are identical. Minimum order for recycled is 800 meters. Please request a recycled swatch and a copy of the GRS certificate for verification.
Q5: What is the typical lead time for this fabric?
For stock gingham color combinations, lead time is 25‑30 days after order confirmation. For custom check colors (e.g., custom Pantone pairs), add 10‑12 days for lab dip development and approval. Bulk production then takes 25‑30 days. Expedited service may be available for orders ≥2000 meters – please inquire.
Q6: How do I care for garments made from this stretch gingham?
Machine wash cold (30°C) gentle cycle with like colors. Do not bleach. Tumble dry low or hang dry. Do not use fabric softener; it can coat the spandex fibers and reduce stretch recovery. Iron on low (synthetic setting) if needed.
Q7: Can I customize the gingham check size or colors?
Yes. Standard check size is approximately 0.5‑0.8 cm. We can produce custom check sizes (0.3‑1.5 cm) and any two‑color combination (e.g., teal/white, maroon/gold). Minimum order for custom designs is 500 meters. Lab dip lead time is 12‑15 days. Stock options include black/white, navy/white, red/white, and pink/white.
This technical data sheet is based on production samples of DHM1666 gingham plaid. Stock colors MOQ: 200 linear meters. Custom colors MOQ: 500 meters. Recycled version MOQ: 800 meters. Lead time: 25‑30 days for stock colors, 35‑42 days for custom colors (including lab dip).
